Position

Name

Description/Value

9

Reserved

Filler "_"

10-11

Revision

EDR revision number, 0-255, represented at a 2-digit Hex value.

12-13

Reserved

Filler "_"

14-17

Record Length

Length of records represented as a 4-digit Hex value

18-25

Ops Token

Token value represented as an 8-digit Hex value
